High-Impact Indoor & Outdoor LED Video Walls for Advertising & Branding
Up to 10,000 nits for perfect visibility even in direct sunlight conditions.
Complete dust and water resistance for reliable outdoor performance.
Operates from -30°C to +60°C for extreme climate conditions.
Engineered to withstand high winds with minimal surface area and strong mounting.
Advanced power management reduces energy consumption by up to 40%.
Front and rear serviceable modules for quick repairs without dismounting.
Cloud-based CMS for content scheduling, monitoring, and diagnostics.
Modular construction allows virtually unlimited screen sizes and shapes.
Our outdoor LED signage delivers unmatched visibility with brightness levels up to 10,000 nits. Advanced auto-brightness adjustment ensures optimal viewing in any lighting condition while conserving energy.
Engineered to withstand extreme weather conditions with IP65/IP68 rated cabinets. Corrosion-resistant materials and sealed enclosures protect against rain, dust, humidity, and salt spray.
Choose from a wide range of pixel pitch options from 2.5mm to 16mm to match your viewing distance and budget. Fine pitch for close viewing, wider pitch for long-distance visibility.
The included cloud-based CMS lets you schedule content, manage multiple displays, and monitor performance from anywhere. Real-time alerts for brightness, temperature, and module health.
| Specification | Indoor P2.5 | Indoor P4 | Outdoor P4 | Outdoor P6 | Outdoor P10 |
|---|---|---|---|---|---|
| Application | Indoor | Indoor | Outdoor | Outdoor | Outdoor |
| Pixel Pitch (mm) | 2.5 | 4.0 | 4.0 | 6.0 | 10.0 |
| Brightness (cd/m²) | 1000 | 1500 | 5500 | 6500 | 8000 |
| Refresh Rate (Hz) | 3840 | 3840 | 3840 | 3840 | 3840 |
| Viewing Angle (H/V) | 160°/160° | 160°/160° | 140°/140° | 140°/140° | 140°/140° |
| IP Rating (Front/Rear) | IP40/IP21 | IP40/IP21 | IP65/IP54 | IP65/IP54 | IP68/IP65 |
| Cabinet Size (mm) | 500x500 | 500x500 | 960x960 | 960x960 | 960x960 |
| Cabinet Weight (kg) | 7.5 | 7.5 | 38 | 35 | 32 |
| Operating Temp | -10°C~50°C | -10°C~50°C | -30°C~60°C | -30°C~60°C | -30°C~60°C |
| LED Lifespan (Hours) | 100,000 | 100,000 | 100,000 | 100,000 | 100,000 |
| Grey Scale | 16 bit | 16 bit | 16 bit | 16 bit | 16 bit |
| Service Access | Front/Rear | Front/Rear | Front/Rear | Front/Rear | Front/Rear |
| Power (Avg) W/m² | 180 | 150 | 280 | 250 | 220 |
| Warranty | 3 Years | 3 Years | 3 Years | 3 Years | 3 Years |
Eye-catching displays that drive foot traffic and showcase promotions.
High-impact advertising that captures attention day and night.
Large-scale displays for scores, replays, and sponsor content.
Transform buildings into stunning visual landmarks.
Contact our team for a personalized consultation and quote for LED Signage solutions.
